Rabbit Locomotion Study

European rabbit (Oryctolagus cuniculus)

>>Saltatorial locomotion/ digitigrade locomotion
refers to a form of locomotion in which the animal hops as it moves along. This is found in jackrabbits, the western jumping mouse, and even mule deer appear to utilize a form of saltatorial locomotion where all four feet are off the ground at the same time and they run in a springy fashion.

The locomotor pattern of saltation (hopping) is confined mainly to kangaroos, anurans (tailless amphibians), rabbits, and some groups of rodents in the vertebrates and to a number of insect families in the arthropods. All saltatory animals have hind legs that are approximately twice as long as the anteriormost legs. Although all segments of the hind leg are elongated, two of them—the tibial (between upper segment and ankle) and tarsal (ankle) segments—are the most elongated.
There are at least four different saltatory patterns, but all are similar in that the simultaneous retraction or extension of the hind legs is followed by an aerial phase of movement. The aerial phase in all patterns is governed by the physical principles of ballistics (the flight characteristics of an object): the height and the length of the jumps are functions of the takeoff velocity and angle. The longest jumps are attained when the takeoff angle is 45°.
Before jumping, the femur (upper segment of the hind leg) of the flea is held perpendicular to the ground, the tibia extends obliquely posterior, and the remainder of the hind leg extends posteriorly along the ground. Just prior to the jump, the middle legs flex and tilt the body upward; then the femur of the hind legs swings sharply backward simultaneously with the extension of the tibia. This retraction forces the animal upward and forward at an angle of 50°. As the flea approaches touchdown, the front legs are swung forward and downward, the middle legs are held perpendicular to the body axis, and the hind legs project obliquely posterior. The anterior two pairs of legs thus act to absorb the landing shock.

The positions and movements of the hind legs in rabbits and kangaroos are similar to those of the frog. The major difference is that rabbits, kangaroos, and all other mammals move their legs in a vertical plane instead of a horizontal plane, as do the frogs; because the femur and tibia move vertically, the tarsus need not be elevated to prevent the hind leg from hitting the ground.

The saltatorial gait of rabbits is quadrupedal, whereas that of kangaroos is bipedal. A jumping rabbit stretches forward and lands on its forefeet; generally, both forefeet do not touch ground simultaneously, however. As the forefeet touch, the back flexes, and the hind end rotates forward and downward. The hind feet touch down lateral to the forefeet, and, as the back extends, a new jump begins. In contrast, the kangaroo lands on its hind feet, and the back is held fairly straight through all phases of the jump, although the body inclines forward at takeoff and posteriorly when landing.

“That’s why we don’t have front wheel drives”


Reference books/ papers:
Mammalogy: Adaptation, Diversity, Ecology
The Johns Hopkins University Press September 7, 2007

Principles of Animal Locomotion
Princeton University Press (November 25, 2002)

Animals in Motion
Dover Publications; 1ST edition (June 1, 1957)

Muscle and sarcomere lengths in the hind limb of the rabbit (Oryctolagus cuniculus) during a galloping stride (pages 373–383) Nicola J. Dimery(1985)

Tuesday, February 7, 2012

Leaping Lizard inspire robot design

I found this article a while ago when I was looking for reference for the animal study.

UC Berkeley Leaping Lizard


It is amazing to learn that a tail can has such an impact in an animal locomotion.
And more important, found this video continue to track back to the 1993's Jurassic Park, where they finally realized the film actually captured the correct tail movement before the theropod dinosaurs jumped.


Full Article here.
